LinphoneやFlexispをビルドする際に必要なlinphone-sdkのDockerイメージを事前にビルドします。Ubuntu 20.04版Dockerfileは提供されていないため、Ubuntu18.04版Dockerfileをベースに新規作成します。
linphone-sdkソースのダウンロード
必要なのは、 Ubuntu20.04 ベースで linphone-sdk に必要なパッケージをインストールしたイメージファイル作成のための docker-files ディレクトリのみです。
docker-files ディレクトリを任意の場所にコピーペースト後、ダウンロードした linphone-sdk は削除して下さい。
$ git clone https://gitlab.linphone.org/BC/public/linphone-sdk.git
dcoker-files ディレクトリ内で bc-dev-ubuntu-18-04-lts をコピーし bc-dev-ubuntu-20-04-lts を作成します。
変更箇所： 18.04 ---> 20.04
追加箇所： 'ENV DEBIAN_FRONTEND=noninteractive`
変更箇所：cmakeバージョン 3.11—>3.21
# Install CMake 3.21
RUN curl -o cmake.tar.gz https://cmake.org/files/v3.21/cmake-3.21.3.tar.gz && \
tar xvzf cmake.tar.gz && rm cmake.tar.gz && cd cmake-3.21.3 && cmake . && make -j5 install && cd .. && rm -rf cmake-3.21.3
変更箇所：python2, python-pip
# Install python3 and python modules.
# This must be done as 'bc' user because some python modules are installed into /usr/local/lib when pip is invoked
# as root, and rpmbuild prevent python from seaching its modules in this prefix. Using 'bc' user make the python
# modules to be installed into /home/bc/.local/lib.
RUN curl https://bootstrap.pypa.io/pip/2.7/get-pip.py --output get-pip.py && \
sudo apt-get install -y python2 python3-pip && sudo apt-get clean -y && \
sudo ln -s /usr/bin/python2.7 /usr/bin/python && \
sudo python2 get-pip.py
# Run the below command after "docker run" in /home/bc
# pip install --user six pystache graphviz && \
# pip3 install --user six pystache graphviz
bc-dev-ubuntu-20-04-lts
FROM ubuntu:20.04
MAINTAINER Ghislain MARY <[email protected]>
# Use a french mirror
RUN sed -i -E 's/(archive|security)\.ubuntu\.com/fr.archive.ubuntu.com/' /etc/apt/sources.list
# Configure locale
RUN apt-get update && \
apt-get install -y locales && \
apt-get clean && \
echo "en_US.UTF-8 UTF-8" > /etc/locale.gen && \
locale-gen
ENV LANG='en_US.UTF-8' LANGUAGE='en_US:en' LC_ALL='en_US.UTF-8'
ENV SHELL=/bin/bash
ENV PS1='\[\e[33m\]\[email protected]>\[\e[0m\] '
# For the problem is tzdata, which stops with the interactive dialog
ENV DEBIAN_FRONTEND=noninteractive
# Install common general tools
RUN apt-get update && \
apt-get install -y nano sudo vim && \
apt-get clean
# Install development tools
RUN apt-get update && \
apt-get install -y alien at autoconf bison ccache clang cmake doxygen elfutils g++ gdb git graphviz intltool libtool lsb-release make nasm ninja-build openssh-client patch yasm && \
apt-get clean
# Install linphone dependencies development packages
RUN apt-get update && \
apt-get install -y libasound2-dev libavcodec-dev libavutil-dev libbsd-dev libegl1-mesa-dev libglew-dev libgsm1-dev libmariadb-dev-compat libmbedtls-dev libopus-dev libpq-dev libpulse-dev libqt5svg5-dev libspeex-dev libspeexdsp-dev libsqlite3-dev libsrtp2-dev libssl-dev libswscale-dev libturbojpeg0-dev libv4l-dev libvpx-dev libxerces-c-dev libxml2-dev libxv-dev qt3d5-dev qt5-default qtbase5-dev qtbase5-dev-tools qtconnectivity5-dev qtdeclarative5-dev qtdeclarative5-dev-tools qtdeclarative5-dev-tools qtquickcontrols2-5-dev qttools5-dev qttools5-dev-tools xsdcxx && \
apt-get clean
# Install CMake 3.21
RUN curl -o cmake.tar.gz https://cmake.org/files/v3.21/cmake-3.21.3.tar.gz && \
tar xvzf cmake.tar.gz && rm cmake.tar.gz && cd cmake-3.21.3 && cmake . && make -j5 install && cd .. && rm -rf cmake-3.21.3
# Configure user bc
RUN useradd -ms /bin/bash bc && \
echo 'bc:cotcot' | chpasswd && \
echo 'bc ALL=(ALL) NOPASSWD:ALL' >> /etc/sudoers
# Switch for 'bc' user
USER bc
WORKDIR /home/bc
# Install python3 and python modules.
# This must be done as 'bc' user because some python modules are installed into /usr/local/lib when pip is invoked
# as root, and rpmbuild prevent python from seaching its modules in this prefix. Using 'bc' user make the python
# modules to be installed into /home/bc/.local/lib.
RUN curl https://bootstrap.pypa.io/pip/2.7/get-pip.py --output get-pip.py && \
sudo apt-get install -y python2 python3-pip && sudo apt-get clean -y && \
sudo ln -s /usr/bin/python2.7 /usr/bin/python && \
sudo python2 get-pip.py
# Run the below command after "docker run" in /home/bc
# pip install --user six pystache graphviz && \
# pip3 install --user six pystache graphviz
COPY --chown=bc rpmmacros /home/bc/.rpmmacros
CMD bash
Makefileに上記dockerfileイメージのビルドセクションを追加します。
ubuntu-20.04-LTS:
docker build -f bc-dev-ubuntu-20-04-lts -t $(BASE_NAME)/bc-dev-ubuntu:20.04 --rm .
Ubuntu20.04版linphone-sdk イメージをビルドします。
$ make ubuntu-20.04-LTS
作成イメージ
$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
gitlab.linphone.org:4567/bc/public/linphone-sdk/bc-dev-ubuntu 20.04 88d9f4a2c038 9 minutes ago 2.52GB
ubuntu 20.04 597ce1600cf4 3 days ago 72.8MB
イメージからコンテナ起動
$ docker run --name linphone-desktop -v $PWD:/home/bc -it gitlab.linphone.org:4567/bc/public/linphone-sdk/bc-dev-ubuntu:20.04
bc@410eda0ead5c:~$
